Accuracy, portability, and dependability – This is the reputation the MD400E and MD500E scales have earned over 50 years of highly demanding use in commercial truck weighing, cargo and heavy equipment weighing, law enforcement, military deployments and tough industrial applications.
Easy-to-read in all conditions – With a 16-character large, backlit Liquid Crystal Display (LCD) you can read weight in varied lighting conditions.
Rugged – Virtually indestructible and practically maintenance free.
Versatility – The MD400E and 500E operate wherever needed – in rough environments, on many unconventional and uneven surfaces such as dirt, gravel, tar, cement, and off-level surface areas. A low 20 degree ramp slope and non-skid bottom provide ease of entry and exit of the scale.
Easy Setup – The MD400E;s and MD500E;s are easy to move from axle-to-axle and wheel to wheel. One man can easily carry, setup and weigh using the flexible scale handles. Each scale uses commercially available disposable or rechargeable batteries.
Accuracy – With a remarkable repeatable accuracy of up to + or – 1% of the applied load or 50 pounds, (also available in 25 lbs and 10 lbs). GEC scales exceed all NIST Handbook 44 and NTEP requirements for Class III devices.
Local/Total Function – You can connect as many as 30 scales by cable and display any individual scale weight as well as the total weight readings from any scale in the series. With the local/total feature, no need to go from side to side of the vehicle to record weights, the MD400E’s or MD500E’s do this for you totaling to a single scale.
Click here to get your own MD400E/500E.
MD400E SPECIFICATIONS DATA SHEET
Operating Temperature : 14°F (-10°C) to + 104° F (40°C)
Storage Temperature : -35°F (-37°C) to + 150°F (66°C)
Internal Power Requirements : 12VDC (Rechargeable/ Disposable)
External Power Requirements : 110/220 VAC, 50/60 Hz
Options
- Wireless/Cabled communication
- Switch between Pounds or Kilogram Units
- Weight Management Software Including Center of Balance
- Durable Wireless Handheld Unit
- Detachable Ramps and Spacers
- Multiple Scale Configuration (2,4,6,8)
- Windows 10 Tablet
- Storage Case
Dimension
Overall Length : 20-1/2” inches (52 cm)
Overall Width : 14” inches (35.5 cm)
Height : 3-1/8” inches (8.3 cm)
Weighing Surface
Length : 11” inches (27 cm)
Width : 10-1/2” inches (27 cm)
Weight : 43 lbs (19.5 kgs)
Capacity : 0 to 20,000 lbs (0 to 10,000 Kgs)
Features
- Easy Battery Access
- User Selectable Increments. 1,2,5,10,20,50,100 in lbs. and 1,2,5,10,25,50 in kgs.
- Wireless Mesh network
- Backlight display
- Seamless Data transfer
- 16 Character Alphanumeric LCD
- Cabled to read LCL/TTL weight up to 30 scales
Unlimited Terrain (5% slope)
Weighable on gravel surface
Roll over protected dial
Rugged design
Accuracy (per NIST Handbook 44 for Class IIII devices)
0 to 2,500 lbs. : ± 50lbs.
2,500 to 10,000 lbs. : ± 100lbs.
10,500 to 20,000 lbs. : ± 150lbs.
MD500E SPECIFICATIONS DATA SHEET
Operating Temperature : -14°F (-10°C) to + 104°F (40°C)
Storage Temperature : -35°F (-37°C) to + 150°F (66°C)
Internal Power Requirements : 12VDC (Rechargeable/ Disposable)
External Power Requirements : 110/220 VAC, 50/60 Hz
Options
- Wireless/Cabled communication
- Switch between Pounds or Kilogram Units
- Weight Management Software Including Center of Balance
- Durable Wireless Handheld Unit
- Detachable Ramps and Spacers
- Multiple Scale Configuration (2,4,6,8)
- Windows 10 Tablet
- Storage Case
Dimension
Overall Length : 20-1/2” inches (52 cm)
Overall Width : 17-3/4” inches (45 cm)
Height : 3-1/8” inches (8 cm)
Weighing Surface
Length : 11” inches (27 cm)
Width : 13-1/2” inches (34 cm)
Weight : 50 lbs (22.7 kgs)
Capacity : 0 to 20,000 lbs (0 to 10,000 Kgs)
Features
- Easy Battery Access.
- User Selectable Increments. 1,2,5,10,20,50,100 in lbs. and 1,2,5,10,25,50 in kgs.
- Wireless Mesh network
- Backlight Display
- Seamless Data transfer
- 16 Character Alphanumeric LCD
- Cabled to read LCL/TTL weight up to 30 scales
Unlimited Terrain (5% slope)
Weighable on gravel surface
Roll over dial
Rugged Design
Accuracy (per NIST Handbook 44 for Class IIII devices)
0 to 2,500 lbs. : ± 50 lbs.
2,500 to 10,000 lbs. : ± 100 lbs.
10,500 to 20,000 lbs. : ± 150 lbs.
